TJF1960

I have two Vue on my main panel to offer 32 sensors each for my 32 breakers. The two Vue's are linked together on the same account in the Vue app. It works great for me. 😀

WEBCONTROL832 PLUGIN SETUP GUIDE ** (Note, if you are upgrading from the Non-Production Store version to Production Store version, follow the steps at the bottom of this page). *** Before installing ANY Plugin (nodeserver) ALWAYS do a complete backup of PGx3 and IoX beforehand. (I always do another right after installation for good measure). The WebControl832 Plugin connects to a WebControl8 or WebControl32 device, polling its data and updating your IoX system with the following information: 1. Node Server Status: Displays "Connected," "Not Connected," or "Failed." 2. Heartbeat: Alternates between 1 and -1 when connected, updating with each shortPoll. Displays 0 when disconnected. 3. NetBIOS Name: The name assigned to your WebControl device in its network configuration. 4. Date and Time: The current date and time reported by the WebControl device. 5. IP Address: The IP address assigned to the WebControl device. 6. Firmware Version: The firmware version installed on the WebControl device. POLLING CONFIGURATION • shortPoll: Updates only nodes with changed values since the last poll. Default: 10 seconds. • longPoll: Forces an update of all node values. Default: 10 minutes. ________________________________________ CUSTOM PARAMETERS Configure the following parameters to match your WebControl device settings: • IP_Address: The IP address of the WebControl device. • Port: The WebControl's network port (default: 80). • Username: The WebControl login username (default: admin). • Password: The WebControl login password (default: password). • Json_Nodes_Names: A single-line JSON string specifying which nodes to create and their custom names. See examples below. • Custom_Name: A custom name for the WebControl device (default: WebControl832). ________________________________________ NODE CREATION This plugin only creates the Controller Node by default. Additional nodes must be specified in the Json_Nodes_Names parameter. This ensures that only the nodes you need are created, reducing resource usage. JSON String Format: The JSON string uses a key-value structure: • Key: The node type (e.g., aip1 for Analog Input 1). • Value: The custom name for the node. For example, to create a node for Analog Input 1 and name it "My Analog Input," use: {"aip1": "My Analog Input"} To create multiple nodes (e.g., one Analog Input, one Output, and two Temp Sensors): {"aip1": "Analog Input 1", "op1": "Output 1", "ts1": "Temp Sensor 1", "ts8": "Temp Sensor 8"} ________________________________________ AVAILABLE JSON KEYS Below are the keys and their corresponding WebControl node types: WEBCONTROL 8 • aip1 to aip3: Analog Inputs 1 to 3 • counter: Counter • fcounter: Frequency Counter • hs1: Humidity Sensor • ip1 to ip8: Inputs 1 to 8 • op1 to op8: Outputs 1 to 8 • ts1 to ts8: Temperature Sensors 1 to 8 • var1 to var8: Variables 1 to 8 WEBCONTROL 32 • aip1 to aip8: Analog Inputs 1 to 8 • cnt1 to cnt3: Counters 1 to 3 • hs1: Humidity Sensor • ip1 to ip16: Inputs 1 to 16 • op1 to op16: Outputs 1 to 16 • ts1 to ts16: Temperature Sensors 1 to 16 • var1 to var16: Variables 1 to 16 ________________________________________ EXAMPLE JSON STRINGS WEBCONTROL 8 Here’s a complete JSON string for creating all possible nodes on a WebControl 8 board: {"aip1": "Analog Input 1", "aip2": "Analog Input 2", "aip3": "Analog Input 3", "counter": "Counter", "fcounter": "Frequency Counter", "hs1": "Humidity Sensor", "ip1": "Input 1", "ip2": "Input 2", "ip3": "Input 3", "ip4": "Input 4", "ip5": "Input 5", "ip6": "Input 6", "ip7": "Input 7", "ip8": "Input 8", "op1": "Output 1", "op2": "Output 2", "op3": "Output 3", "op4": "Output 4", "op5": "Output 5", "op6": "Output 6", "op7": "Output 7", "op8": "Output 8", "ts1": "Temp Sensor 1", "ts2": "Temp Sensor 2", "ts3": "Temp Sensor 3", "ts4": "Temp Sensor 4", "ts5": "Temp Sensor 5", "ts6": "Temp Sensor 6", "ts7": "Temp Sensor 7", "ts8": "Temp Sensor 8", "var1": "Variable 1", "var2": "Variable 2", "var3": "Variable 3", "var4": "Variable 4", "var5": "Variable 5", "var6": "Variable 6", "var7": "Variable 7", "var8": "Variable 8"} WEBCONTROL 32 Here’s a complete JSON string for creating all possible nodes on a WebControl 32 board: {"aip1": "Analog Input 1", "aip2": "Analog Input 2", "aip3": "Analog Input 3", "aip4": "Analog Input 4", "aip5": "Analog Input 5", "aip6": "Analog Input 6", "aip7": "Analog Input 7", "aip8": "Analog Input 8", "cnt1": "Counter 1", "cnt2": "Counter 2", "cnt3": "Counter 3", "hs1": "Humidity Sensor", "ip1": "Input 1", "ip2": "Input 2", "ip3": "Input 3", "ip4": "Input 4", "ip5": "Input 5", "ip6": "Input 6", "ip7": "Input 7", "ip8": "Input 8", "ip9": "Input 9", "ip10": "Input 10", "ip11": "Input 11", "ip12": "Input 12", "ip13": "Input 13", "ip14": "Input 14", "ip15": "Input 15", "ip16": "Input 16", "op1": "Output 1", "op2": "Output 2", "op3": "Output 3", "op4": "Output 4", "op5": "Output 5", "op6": "Output 6", "op7": "Output 7", "op8": "Output 8", "op9": "Output 9", "op10": "Output 10", "op11": "Output 11", "op12": "Output 12", "op13": "Output 13", "op14": "Output 14", "op15": "Output 15", "op16": "Output 16", "ts1": "Temp Sensor 1", "ts2": "Temp Sensor 2", "ts3": "Temp Sensor 3", "ts4": "Temp Sensor 4", "ts5": "Temp Sensor 5", "ts6": "Temp Sensor 6", "ts7": "Temp Sensor 7", "ts8": "Temp Sensor 8", "ts9": "Temp Sensor 9", "ts10": "Temp Sensor 10", "ts11": "Temp Sensor 11", "ts12": "Temp Sensor 12", "ts13": "Temp Sensor 13", "ts14": "Temp Sensor 14", "ts15": "Temp Sensor 15", "ts16": "Temp Sensor 16", "var1": "Variable 1", "var2": "Variable 2", "var3": "Variable 3", "var4": "Variable 4", "var5": "Variable 5", "var6": "Variable 6", "var7": "Variable 7", "var8": "Variable 8", "var9": "Variable 9", "var10": "Variable 10", "var11": "Variable 11", "var12": "Variable 12", "var13": "Variable 13", "var14": "Variable 14", "var15": "Variable 15", "var16": "Variable 16"} ________________________________________ After updating all custom parameters, click Save. The controller node (NetBIOS name, date/time, IP address, and firmware version) will update during the next longPoll. Additional nodes will begin updating shortly after saving or restarting the plugin. ________________________________________ ** If you have the Non-Production version installed and would like to upgrade to the Production version, Follow the steps below. 1) Backup PGx3 and IoX completely. 2) Go to the PGx3 Production store and find WebControl832 and select. 3) On the install page, verify your beta version and slot number is listed. Then select install. 4) On the pop up page you will see a box labeled Reinstall Here for each instance of the plugin you have installed. 5) Select Reinstall Here button and wait 30 seconds for the plugin to update and start up again. Do this for every instance. 6) Backup PGx3 and IoX completely for good measure. 12/31/2024 Production start version v1.0.3

Hey Eric, Cool! I figured hs would work but not having a way to test, you really helped me out. Thanks for confirming. I can confirm AIP, OP, TS and Var are working on my end as well so you should be good to go. Appreciate your time and patience. Happy Holidays!

Hey Eric, Give v1.0.3 a try. Please let me know. Thanks! -Tim

Got it. Thank you! I will let you know in a day or two, just as soon as I can. -Tim

I am so sorry for the issues you are having. I do not have a humidity sensor to test off of. It is being created based on similar config as temp sensors. I will have more to go on once I see your logs. IP values were working correctly however in my current set up involving 3 WC boards, none use IP. I will hook up my 4th board for testing those values. In the mean time, do me a favor. in the plugin for WebControl832 in PGx, set the plugin logging for "info" then stop the plugin, wait a few seconds and restart it. Give me about 5 minutes of data then turn the logging back to where it was, download the package and PM me. Also, please supply in the same email your json. I will look into this, again I apologize. -Tim

Wow. Never have seen that before! The bottom half should be all that is displayed. I would delete the plugin and reinstall. Its almost like there was left over artifacts between original install and update. Try a delete and reinstall and let me know. -Tim

I did some renaming of the custom params between v1.0.1 and 1.0.2, did you upgrade from a previous version or did you install fresh the 1.0.2 version? -Tim

Sorry, not following. Can you Screenshot. I am not seeing double inputs in the config setup in PGx.

Awesome! Good to know. Thank you!

I had a lot of trouble with uploading the files to the beta store yesterday and again this morning. But everything should be good now. I just double checked and I see 43 plugins in the beta store, 2 of which are mine. You will want to delete both instances in pgx and reinstall fresh. If you do not see it in the beta store, hit refresh. Let me know if that works.

I have been testing it here on both my eISY's, wanted to make sure it was good to go before contacting you. So far its good for me too. There was a snafu with the zip folder when it was uploaded to UDI's servers, but all good now. Thanks for letting me know! -Tim

Odd, when I get home I will check to see what is going on and get back to you. -Tim

Hi @dbwarner5, please give 1.0.12 a go. -Tim

@dbwarner5, I will look over the NLS file and update it, I may not get it done until this weekend but I will try for sooner. I will update the store when complete.
